Horizontal Accumulator For The Payoff Or Takeup Operation
  • name

Horizontal Accumulator For The Payoff Or Takeup Operation

MOQ: 1 set
Price: negotiable
Standard Packaging: according to customer's requirements
Delivery Period: 30-120 days
Payment Method: T/T, L/C
Detail Information
Product Description
Detail Information
Place of Origin
Wuxi
Brand Name
HNT
Certification
ISO9001:2008, CE, High-tech enterprise
Wheel Diameter:
300/400mm
Conductor Diameter:
Max. 1000mm
Accumulator Length:
120m
Line Speed:
Max. 1000 M/min
Machine Length:
12M
Moving Wheels:
4
Highlight:

Horizontal Accumulators

,

rewinding line Horizontal Accumulator

,

Payoff Horizontal Accumulator

Product Description

Horizontal Accumulator:

  1. Application: for the extrusion non-stop production or rewinding line;
  2. Length: horizontal 12 meters;
  3. Stretching force: 2.2KW variable frequency AC motor;
  4. Applicable wire diameter: φ0.9-φ15mm;
  5. Tension form: 20KG magnetic powder clutch;
  6. Range of tension: ≤1400N;
  7. Wire Storage length: 200m;
  8. Guide wheel: diameter 300/400mm, material is alloy aluminum, surface anodized hardening, the number of wheels is 10+11 wheels;
  9. Anti-collision: compression spring;
  10. Safety device: limit contact detection, disconnection and shutdown;
  11. Tension output form: detected from the encoder, the tension changes linearly according to the change of the position of the storage line.

Horizontal Accumulator For The Payoff Or Takeup Operation 0

Tags:

Horizontal Wire Accumulator,

Wire Coil Dispenser Accumulator,

220KV Wire Accumulator
