Power Cable Jacket Extrusion Line is designed for HV cable jacket or sheath extrusion. Applicable extrusion materials PVC, PE, LDZH, LDLH, semi-conducting PVC, semi-conducting PE and etc.

Technical Parameter:

Model	Φ200 + Φ120
Screw diameter	Φ200 mm + Φ120 mm
Extrusion amount	400 kg/hr
Viable conductor shape	Circular, Sector, Stranded, Solid
Applicable material	PVC, PE, LDZH, LDLH, semi-conducting PVC, semi-conducting PE
Control mode	PLC
Max line speed	80 m/min
Wire diameter control precision	±0.02 mm

Line components;

Main Parts of Line	Qty
Portal driven type pay off	2
TQD3200kg Belt caterpillar(before extruder)	1
Bitumen Coating machine	1
Main extruder	1
Φ180mm cross head	1
Given material loading system & dryer (500kg/1000kg)	2
24m stainless steel cooling trough (400*350mm)	1
Dryer device	1
TQD3200kg caterpillar (after extruder)	1
Graphite coating machine	1
PN2500-5000mm portal type take up 35T	2
Electric control system	1

PVC Power Cable, PVC Jacket Cable Sheath Extrusion Line 1

Tags:

400m/Min Cable Extrusion Line,

1000m/Min Cable Extrusion Line,

70mm PP Extrusion Machine

Electric Wire Extrusion Line

Contact Now

Wire Insulation Line

Contact Now

Video

Rigid Conductor PVC Insulation Wire Extrusion Machine

Contact Now

Video

Silicohydride Crosslinking Insulation Extrusion Line

Contact Now

ABC Aluminum Aerial Bundled Overhead Cable Insulation Extrusion Line

Contact Now

Stranded Wire Power Cable Sheathing Machine

Contact Now

φ90mm cable extruder Machine

Contact Now

PRODUCTS DETAILS

Products

Wire Stranding Machine

Rigid Stranding Machine

Tubular Stranding Machine

Double Twist Stranding Machine

Cable Extrusion Line

Cable Packing Machine

Shrink Packaging Machine

Wire Take Up Machine

Wire Payoff Machine

Armoring Machine

Caterpillar Capstan

Wire Accumulator

Rewinding Lines

Cable Materials

PVC Power Cable, PVC Jacket Cable Sheath Extrusion Line

MOQ:	1 set
Price:	negotiable
Standard Packaging:	according to customer's requirements
Delivery Period:	30-120 days
Payment Method:	T/T, L/C

Detail Information

Product Description

Detail Information

Place of Origin

Wuxi

Brand Name

HNT

Certification

ISO9001:2008, CE, High-tech enterprise

Extrusion Material:

PVC, PE, LDZH, LDLH, Semi-conducting PVC, Semi-conducting PE

Function:

HV Cable Jacket Or Sheath Extrusion

Line Speed:

80 M/min

Conductor Shape:

Circular, Sector, Stranded, Solid

After-sales Service Provided:

Engineers Available To Service Machinery Overseas

Warranty:

1 Year

Minimum Order Quantity:

1 set

Price:

negotiable

Packaging Details:

according to customer's requirements

Delivery Time:

30-120 days

Payment Terms:

T/T, L/C

Highlight

power cable Sheathing Line Machine

HV Sheathing Line Machine

high voltage cable sheathing lines

Product Description

Power Cable Extrusion Line:

Power Cable Jacket Extrusion Line is designed for HV cable jacket or sheath extrusion. Applicable extrusion materials PVC, PE, LDZH, LDLH, semi-conducting PVC, semi-conducting PE and etc.

Technical Parameter:

Model	Φ200 + Φ120
Screw diameter	Φ200 mm + Φ120 mm
Extrusion amount	400 kg/hr
Viable conductor shape	Circular, Sector, Stranded, Solid
Applicable material	PVC, PE, LDZH, LDLH, semi-conducting PVC, semi-conducting PE
Control mode	PLC
Max line speed	80 m/min
Wire diameter control precision	±0.02 mm

Line components;

Main Parts of Line	Qty
Portal driven type pay off	2
TQD3200kg Belt caterpillar(before extruder)	1
Bitumen Coating machine	1
Main extruder	1
Φ180mm cross head	1
Given material loading system & dryer (500kg/1000kg)	2
24m stainless steel cooling trough (400*350mm)	1
Dryer device	1
TQD3200kg caterpillar (after extruder)	1
Graphite coating machine	1
PN2500-5000mm portal type take up 35T	2
Electric control system	1
