Max. 50mm² Cable Wire Coil Wrapping Machine

MOQ: 1 set
Price: negotiable
Standard Packaging: according to customer's requirements
Delivery Period: 30-120 days
Payment Method: T/T, L/C
Detail Information
Product Description
Detail Information
Place of Origin
Wuxi
Brand Name
HNT
Certification
ISO9001:2008, CE, High-tech enterprise
Max. Coil OD:
φ600mm
Coil Inner ID:
Max. φ300mm
Function:
Coiling & Wrapping
Wrapping Material:
PVC, PVE
Application:
Cable Coiling And Wrapping
Warranty:
One Year
Highlight:

C1860 wire wrap machine

,

C1860 Cable coiling and wrapping machine

,

C1860 Coil Wrapping Machine

Product Description

Cable Wrapping Machine



Machine Main Feature:

  1. Connect with the extrusion line for the non-stop cable coiling and wrapping operation.
  2. Machine with Auto holding arm adjust system after finished coiling.
  3. With Auto labeling machine, saving labor cost,safe and convenience.
  4. Can connect with robot stacking system.
  5. Microcomputer memory can store 99 different specifications of wire coil. When you need to change the productspecifications, you just need to read the data of the stored specifications. No need to input again, and you can produce immediately.
  6. Traverse device: by adopts Mitsubishi servo motor and synchronizes with the main machine of coiling.
  7. Whole machine electrical circuit control: Mitsubishi microcomputer programmable controller (PLC).

Technical Parameter:

Model Coil Height (mm) Coil O.D (mm) Coil I.D (mm) Cable Dia. (mm)

Packing

Material

 Speed Robot Auto Stacking
TP460 60-100 240-460 170-220 4-12 PVC 2-2.6Coil/M Can be choosed
TP600 80-180 320-600 200-300 5-20 PVE 1.5-2 Coil/M Can be choosed





Max. 50mm² Cable Wire Coil Wrapping Machine 0Max. 50mm² Cable Wire Coil Wrapping Machine 1



Tags:

Cable Packing Machine,

180mm Plastic Wrapping Machine,

180mm Cable Packing Machine
