C1246 Cable Coil Wrapping Machine C1246 Steel Coil Wrapping Machine

MOQ: 1 set
Price: negotiable
Standard Packaging: according to customer's requirements
Delivery Period: 30-120 days
Payment Method: T/T, L/C
Detail Information
Product Description
Detail Information
Place of Origin
Wuxi
Brand Name
HNT
Certification
ISO9001:2008, CE, High-tech enterprise
Max. Coil OD:
φ600mm
Line Speed:
Max. 300m/min
Coil ID:
Max. 300
Robot Stacking:
Yes (If You Need)
Wrapping Material:
PVC, PVE
Application:
Cable Coiling And Wrapping
Highlight:

c1246 cable coil wrapping machine

,

c1246 cable coil wrapping machine

,

c1246 steel coil wrapping machine

Product Description

Cable Coil Wrapping Machine



Machine Main Feature:

  1. Connect with the extrusion line for the non-stop cable coiling and wrapping operation.
  2. Machine with Auto holding arm adjust system after finished coiling.
  3. With Auto labeling machine, saving labor cost,safe and convenience.
  4. Can connect with robot stacking system.
  5. System with automatic detection function, when problem come out, the machine can auto detect the mistakes, and send message to warn the operator.
  6. Operation control Method:Touch screen+PLC；
  7. Machine design Line speed:Max300M/min;
  8. Microcomputer memory can store 99 different specifications of wire coil. When you need to change the productspecifications, you just need to read the data of the stored specifications. No need to input again, and you can produce immediately.
  9. Traverse device: by adopts Mitsubishi servo motor and synchronizes with the main machine of coiling.
  10. Whole machine electrical circuit control: Mitsubishi microcomputer programmable controller (PLC).
  11. Instrument and switch on the operation panel: touch screen, speed adjustment button.
  12. Speed can be adjusted on the touch screen or the speed adjustment button.

Technical Parameter:

Model Coil Height (mm) Coil O.D (mm) Coil I.D (mm) Cable Dia. (mm)

Packing

Material

 Speed Robot Auto Stacking
TP460 60-100 240-460 170-220 4-12 PVC 2-2.6Coil/M Can be choosed
TP600 80-180 320-600 200-300 5-20 PVE 1.5-2 Coil/M Can be choosed



C1246 Cable Coil Wrapping Machine C1246 Steel Coil Wrapping Machine 0

C1246 Cable Coil Wrapping Machine C1246 Steel Coil Wrapping Machine 1

Tags:

Cable Packing Machine,

180mm Plastic Wrapping Machine,

180mm Cable Packing Machine
