Stranded Wire Power Cable Sheathing Machine
  • name

Stranded Wire Power Cable Sheathing Machine

MOQ: 1 set
Price: negotiable
Standard Packaging: according to customer's requirements
Delivery Period: 30-120 days
Payment Method: T/T, L/C
Detail Information
Product Description
Detail Information
Place of Origin
Wuxi
Brand Name
HNT
Certification
ISO9001:2008, CE, High-tech enterprise
Model Number
φ70mm Extrusion Line
Application Material:
PVC, LDPE, MDPE, HDPE, HFFR
Product Range:
Cable Dia. Up To 200mm
Line Speed:
50m/min
Certification:
CE,ISO9001
Screw Design:
Single-screw
After-sales Service Provided:
Engineers Available To Service Machinery Overseas
Warranty:
12 Months
Motor:
SIEMENS Brand
Highlight:

Sheathing Machine Power Cable

,

Cable Sheathing Machine

,

Power Cable Sheathing Machine

Product Description

Power Cable Sheathing Machine:

  1. Line configurations for different production speeds and spaces according to your requirements
  2. Line can be equipment with tandem extruder for sheathing process
  3. Specific screws and barrels can be chosen to match the material for extrusion, such as PVC, LDPE, MDPE, HDPE, HFFR and etc.
  4. The extrusion crosshead of EX series can be selected from center-adjusted or adjustless, strip color and skin color can be adopt.
  5. Line can connect with portal takeup and payoff,and belt type caterpillar
  6. Crosshead clampers of EX series are double-tooth rod chain driven, and other fixed parts has the function of auto-centering.
  7. Tem-control is from Japanese RKC series tem-controller &solidity repay(SSR).

Extrusion Type:

Stranded Wire Power Cable Sheathing Machine 0

Technical parameter:

Model Φ200 + Φ120
Screw diameter Φ200 mm + Φ120 mm
Extrusion amount 400 kg/hr
Viable conductor shape Circular, Sector, Stranded, Solid
Applicable material PVC, PE, LDZH, LDLH, semi-conducting PVC, semi-conducting PE
Control mode PLC
Max line speed 80 m/min
Wire diameter control precision ±0.02 mm





Stranded Wire Power Cable Sheathing Machine 1
