High Speed Wire Pay Off Flyer Pay-Offs And Take-Ups
High speed Wire Pay Off
,1250mm Bobbin Wire Pay Off
,Flyer Pay-Offs and Take-Ups
Flyer Payoff
Machine description:
High speed pay-off up to 1000 meters；
According customers' requirements can be made single flyer or double flyer payoff;
The flyer Pay-off is designed for continuous, silent and smooth flow of wire at high speed production. Special design for the fly-off cone geometry in order to minimize stress on the wire when paying-off at high speeds. Cast iron or steel material can be choosed.
The pay-off comprises of single or double cones and central wire guide is include. The inside surface of the cones are machined and have a longitudinal slot on one side to enable wire fly-off change over from one cone to the other for continuous production. Each cone has a reel holder with a driven shaft. The reel holder hangs on the cone to free the loading trolley. Included in a basic machine is one pair of fly-off flanges for each reel size and one pair of reel shaft adapters for one reel centre hole dimension.
Technical Parameter:
| Model | Inner diameter (mm) | Outer diameter (mm) |
| 800M | 630 - 800 | 475 - 600 |
| 1000M | 800 - 1000 | 600 - 750 |
| 1250M | 1000 - 1250 | 750 - 950 |
