60m/Min single Twist Stranding Machine Cantilever Double Twist Stranders

MOQ:	1 set
Price:	negotiable
Standard Packaging:	according to customer's requirements
Delivery Period:	30-120 days
Payment Method:	T/T, L/C

Detail Information

Product Description

Detail Information

Place of Origin

Wuxi

Brand Name

HNT

Certification

ISO9001:2008, CE, High-tech enterprise

Application Reel Dia.:

800

Line Speed:

Max. 60m/min

Applicable Core Wire:

Ф0.6-6.0mm

Stranded Outer Diameter:

Max.15mm

Function:

Twist/stranding Wires

Twisting Distance Range:

20~200mm

Minimum Order Quantity:

1 set

Price:

negotiable

Packaging Details:

according to customer's requirements

Delivery Time:

30-120 days

Payment Terms:

T/T, L/C

Highlight

60m/min single Twist Stranding Machine

Cantilever single Twist Stranding Machine

Cantilever single Twist Strander

Product Description

High Speed Cantilever Single Twist Bunching Machine

Application:
The equipment is suitable for core wire stranding of PE, PVC coated wires and various cables.

Performance characteristics:

Applicable core wire: Ф0.6-6.0mm.
Stranded outer diameter: MAXФ15mm,
Twisting distance range: 20~200mm.
Reel diameter: Ф800mm.
Speed of cantilever single winch: 600 rpm.
Direction: Left and right "S", "Z" can be switched.
Operation mode: touch screen operation.
Production line speed: 0-60m/min

800 cantilever single winch:

Main motor: 11KW;
Main inverter: 11KW;
Brake: 10KG pneumatic disc brake;
Speed regulating motor: 3.7KW;
Speed control inverter: 3.7KW;
Traverse: The motor drives the lead screw for cable arrangement. Motor: power 1/2HP, reduction ratio: 6:1,
Specification of take-up reel: Φ800;
Reel locking: manual locking.
Reel lift: electro-hydraulic lift.
Man-machine interface operation: The twist distance, speed, and meter can be recorded, displayed and set at any time, and have common
Fault display; color touch screen: 8 colors 6 inches.
PLC programmable controller specification model: SIEMENS S7-200 CPU266;
Specification and model of rotary encoder: Japan Rheinland CB-2000HC;
Type of meter: meter is recorded in the machine and displayed on the touch screen;
Disconnection type meter in place alarm and stop;
Safe operation limit.
