C1246 Automatic Coiling And Strapping Cable Packing Machine For Wire And Cable
C1246 Automatic Coiling And Strapping Cable Packing Machine For Wire And Cable
Basic Properties
Place of Origin:
Wuxi
Brand Name:
HNT
Certification:
ISO9001:2008, CE, High-tech enterprise
Trading Properties
Minimum Order Quantity:
1 set
Price:
negotiable
Payment Terms:
T/T, L/C
Product Summary
C1246 Automatic Coiling And Strapping Machine Machine Main Feature: Connect with the extrusion line for the non-stop cable coiling and binding operation. Machine with Auto holding arm adjust system after finished coiling. Machine can be connected with labeling machine. Can also choose robot stacking ...
Product Custom Attributes
Highlight
C1246 automatic strapping machine
,cable coiling and wrapping packing line
,Coiling Strapping Machine C1246
Max. OD Of Coil:
φ460mm
Height Of Coil:
100mm
Inner Dia.:
Max. 200mm
Width Of Tape:
15mm
Line Speed:
Max. 200m/min
Control Method:
Touch Screen + PLC
Product Description
Detailed Specifications & Features
C1246 Automatic Coiling And Strapping Machine
Machine Main Feature:
- Connect with the extrusion line for the non-stop cable coiling and binding operation.
- Machine with Auto holding arm adjust system after finished coiling.
- Machine can be connected with labeling machine.
- Can also choose robot stacking system for full automatic running of the packing.
- System with automatic detection function, when problem come out, the machine can auto detect the mistakes, and send message to warn the operator.
- Microcomputer memory can store 99 different specifications of wire coil. When you need to change the productspecifications, you just need to read the data of the stored specifications. No need to input again, and you can produce immediately.
- Traverse device: by adopts Mitsubishi servo motor and synchronizes with the main machine of coiling.
- Instrument and switch on the operation panel: touch screen, speed adjustment button.
- Speed can be adjusted on the touch screen or the speed adjustment button.
- The machine PLC has the power frequency sparker contact(the power frequency spark machine is provided by the customer)
Technical Parameter:
| Model | Coil Height (mm) | Coil O.D (mm) | Coil I.D (mm) | Cable Dia. (mm) |
Packing Material |
Speed | Robot Auto Stacking |
| C1246 | 50-100 | 240-460 | 120-200 | 1-10 | PVC | 2-2.6Coil/M | Can be choosed |
| C1860 | 60-180 | 200-600 | 180-250 | 5-15 | PVE | 1.5-2 Coil/M | Can be choosed |
