MHEDB1600/5+6/120 Crosslinked Accumulator;
Structure: Horizontal movable wire accumulator;
Application for the cross-linking production line;
The wire accumulator is equipped with a pneumatic clamping device.
The tension of the cable between the two wheels is controlled electrically.
Different cables use corresponding traction speed, which can be realized by motor speed regulation.
The reserve line brake is automatic.
The tension at the outlet of the accumulator is constant.

Technical Parameter:

Model	MHEDB1600/5+6/120
Accumulator wheel diameter	2000 mm
Maximum conductor diameter	1000 mm²
Accumulator Length	120 m
Number of moving wheels	4
Number of stationary wheels	5
installation length	15M
wire storage material	Aluminum alloy
Maximum design line speed	25 m/min
line speed is continuously adjusted by the variable frequency drive and the AC motor	1-25m/min

MHEDB1600/5+6/120 Wire Accumulator For MV Cables 0

MHEDB1600/5+6/120 Wire Accumulator For MV Cables 1
