Wire Insulation Line
Wire Insulation Line
Basic Properties
Place of Origin:
Wuxi
Brand Name:
HNT
Certification:
ISO9001:2008, CE, High-tech enterprise
Trading Properties
Minimum Order Quantity:
1 set
Price:
negotiable
Payment Terms:
T/T, L/C
Product Summary
Wire Insulation Line: Application for the building wire & electric wire inusulation; Line speed can be choose according to the takeup, Max 1000m/min; Takeup can be Automatic Dual reel take, manual takeup and coiling packing machine, configuration can be choose according to customer's requirements; ...
Product Custom Attributes
Highlight
Wire Insulation Line
Application:
Wire Insulation
Extruder Model:
φ80mm Extrusion
Line Speed:
According To Takeup Max. 1000m/min
After-sales Service Provided:
Engineers Available To Service Machinery Overseas
Plastic Processed:
PVC,PE,PP,HDPE
Warranty:
1 Year
Product Description
Detailed Specifications & Features
Wire Insulation Line:
- Application for the building wire & electric wire inusulation;
- Line speed can be choose according to the takeup, Max 1000m/min;
- Takeup can be Automatic Dual reel take, manual takeup and coiling packing machine, configuration can be choose according to customer's requirements;
- Specific screws and barrels can be chosen to match the material for extrusion, such as PVC, PE, LSNH, Teflon, Nylon and etc.
- The extrusion crosshead of EX series can be selected from center-adjusted or adjustless, strip color and skin color can be adopt.
Technical parameter:
| Model | Screw parameter | Max Extrude capacity (kg/hr) | Finished Outer Diameter (mm) | ||||
| Diameter (mm) | L/D | Speed (RPM) | PVC | LDPE | LSNH | ||
| EX-40G | 40 | 26:1 | 120 | 24 | 14 | 0.8-3 | |
| EX-50G | 50 | 26:1 | 120 | 60 | 35 | 1-6 | |
| EX-60G | 60 | 26:1 | 120 | 100 | 60 | 22 | 2-8 |
| EX-70G | 70 | 26:1 | 120 | 160 | 130 | 36 | 3-15 |
| EX-80G | 80 | 26:1 | 110 | 220 | 180 | 48 | 5-20 |
| EX-90G | 90 | 26:1 | 100 | 310 | 240 | 65 | 8-25 |
| EX-100G | 100 | 25:1 | 90 | 400 | 90 | 10-30 | |
| EX-120G | 120 | 25:1 | 90 | 550 | 15-40 | ||
| EX-150G | 150 | 25:1 | 60 | 900 | 550 | ||
| EX-200G | 200 | 25:1 | 60 | 1300 | 1100 | 750 | |
