| MOQ: | 1 set |
| Price: | negotiable |
| Standard Packaging: | according to customer's requirements |
| Delivery Period: | 30-120 days |
| Payment Method: | T/T, L/C |
Single Wire High-Speed Concentric Stranding Line For Copper Wire And Aluminum Wire
1. Application for the production of all types of High Voltage and Extra-high Voltage Power cable, from overhead to insulated, AC type (using high-quality Milliken conductor) or DC type (using large round compacted conductor or trapezoidal wires);
Advantages of the machine:
1. Due to the concentric structure of the cage (the center of the payoff bobbin and the rotation center of the cage coincide), the centrifugal force of each bobbin is very small, so the rotating speed of the cage is higher and the stranding speed is faster, and the production efficiency is improved;
2. The storage bobbin of the cage with large loading capacity, and does not require frequent loading and unloading, which greatly reduced the amount of labor for the operator;
Main Technical Parameter:
| Dia. of single Copper wire | Φ1.7～Φ4.5mm |
| Dia. of single Alumium wire | Φ1.8～Φ5.0mm |
| Dia. of single Alumium Alloy | Φ1.7～Φ4.5mm |
| Max. stranded wire dia. | Φ45mm |
| Lay length | 40～350mm(step-less adjust) |
| Max rotate speed | 500rpm |
| Max line speed | 100m/min |
| Max rewinding speed | 150～200m/min |
| Bobbin size of cage | 1100×500×200mm |
| Rewinding Pay-off | Φ600×Φ1060×H1730mm |
| Cage rotate motor | AC |
| 12 cage | 55kW |
| 18 cage | 75kW |
| 24 cage | 90kW |
|
|
